The VRS T handguard replaces the factory delta ring and utilizes a proprietary Diamondhead barrel nut.
DIAMONDHEAD KEYMOD ACCESSORIES FREE
BCM KeyMod screws are covered under US Patent 9377274.DiamondheadÆs innovative VRS T-KeyMod-308H Free Floating Handguards offer an uninterrupted rail extension & handguard in perfect alignment with the host weaponÆs flat top receiver.
Recommended torque: 20 inch lbs for both KeyMod screws and light body screws with medium strength threadlocker. Requires a T15 Torx and 5/64" Allen wrench for installation (not included). Includes necessary screws to attach light body to mount. The mount is CNC machined from 7075 -T6 aluminum and MIL-A-8625 Type III hard coat anodized. The Streamlight Protac Rail Mount HL-X is not compatible because the body is longer and covers one mounting screw. Height: 0.20" (at Surefire Scout Light mounting point)Ĭompatible with Surefire M300A, M300B, M300C, M600B, M600C, M600P, M600U, M600V, M600DF, Streamlight Protac Rail Mount 1 and 2, and Arisaka 300 and 600 Series.
DIAMONDHEAD KEYMOD ACCESSORIES SERIES
Another option is to use an Arisaka 300 Series Light Body or 600 Series Light Body, which will allow plenty of clearance. This means one or the other will have to be moved forward/back to get appropriate clearance.
DIAMONDHEAD KEYMOD ACCESSORIES PRO
The smaller sights like MBUS Pro and Knight's Armament Micro work fine, but the Troy, Diamondhead, and MBUS Gen II will not be able to clear the main body where the screw holes reside for the stock picatinny adapter. Top right 45 degree flat: Due to the asymmetrical body of the Surefire Scout Light, placement of the front sight and light are more critical in this setup. MBUS Gen II work if positioned to allow clearance for the release tab.Ģ. Top left 45 degree flat: Most sights work, including MBUS Pro, Knight's Armament Micro, Troy folding, and Diamondhead. Doing so may result in mount failure in the event of a heavy impact to the light.Ĭompatibility with front sights varies depending on mounting location on handguards with 45 degree flats:ġ. This mount is not intended for use in a cantilever fashion where it hangs off the end of the handguard. Installation tip: In order to reduce the overall length of the mount as much as possible, it is necessary to unscrew the tail cap of the light to access the front-most mounting screw. The base of the Surefire Scout Light sits only 0.2" above the mounting surface. Three positions are provided, allowing an offset of 0.12" to either side of center. When used on a 45 degree angle mounting flat, the Inline Scout Mount allows the user to position the light closer or farther away from the top 12 o'clock rail to give clearance for front sights or other accessories. This new version is made of 7075 aluminum for superior strength and uses BCM's patented inverted KeyMod screws with twin recoil lugs for easier installation and a solid connection to your handguard.
The mount is especially useful on handguards that feature 45 degree angle mounting flats, such as the Bravo Company KMR, Daniel Defense MFR, Knight's Armament URX 4, MI Gen 3 and Mega MKM. It replaces the stock Picatinny rail adapter with a low profile mount for KeyMod handguards. The Patented Arisaka Inline Scout Mount is designed specifically for the Surefire Scout Light M600 and M300 series weapon lights, the Arisaka 300 and 600 Series Lights, and the Streamlight Protac Rail Mount 1 and 2.
